Daktronics 5000 Series Service Manual

Introduction
2
Spare Parts
Every Daktronics digital billboard is shipped with spare parts that include commonly
replaced components. The table lists some of the components that may be included in
the spare parts rack shown in Figure 2. Refer to the spare parts inventory list contained in
the bag in the spare parts rack for a list of the parts. Contact the Account Service
Manager (ASM) to order additional spare parts.
Description Daktronics Part Number
Module
Varies by pixel pitch
PLR-6050 W/Hook Mount
0A-1487-6009
28" SATA Cable
W-2410
Power Supply
A-2476
LC-LC Duplex Fiber Cable
W-1767
30' 4 Pin Male to 4 Pin Female Cable
W-1820
3' 3 Pin Male to 3 Pin Female Cable
W-2510
Filters
Modules
Power
Supply
Splice
Wrench
1
/
8
" Hex
Head
Wrench
Torque
Stick
Figure 2: Spare Parts in Spare Parts Rack

Daktronics 5000 Series Specifications

General

Series	5000 Series
Display Type	LED
Pixel Pitch	10mm
Brightness	5000 nits
Viewing Angle	140° horizontal
Operating Temperature	-30°C to 50°C
IP Rating	IP65
