Daktronics 5000 Series Service Manual

Introduction
4
Field Replaceable Units
The table below lists component names and part numbers of components that can be
replaced in the display and the control system. Some of these components are located
in the spare parts rack. Contact the ASM to order components when needed.
Display FRUs Control System FRUs
Description
Daktronics Part
Number
Description
Daktronics Part
Number
Module
Varies by pixel pitch
Meraki Router
A-3665
Surge Suppressor
A-3677
DMP-8065�2
0A-1603-8200
Power Supply
A-2476
Light Sensor
0A-1604-4620
3 Pole Contactor
A-3157
Ethernet Switch
A-1815
Axial Fan �4 A
B-1045
500 W Heater
A-1819
Axial Fan �17 A
B-1094
POE Injector
A-3126
12 VDC Relay
K-1040
Mobotix Webcam
A-3127
28" SATA Cable
W-2885
SmartLink
TM
A-3707
72" SATA Cable
W2889
Temperature Sensor
0A-1151-0013
Line Filter
Z-1002
60 V Surge Protector
A-3159
20 Amp Single Pole Breaker
S-1045
Axial Fan �16 A
B-1053
15 Amp Tandem Breaker
S-1199
Axial Fan �13 A
B-1071
120 VAC Relay
K-1044
Filter
EN-2242
ProLink Router
0A-1487-6009
Transformer
T-1043

Daktronics 5000 Series Specifications

General

Series	5000 Series
Display Type	LED
Pixel Pitch	10mm
Brightness	5000 nits
Viewing Angle	140° horizontal
Operating Temperature	-30°C to 50°C
IP Rating	IP65
