6 Mechanical Installation
Model &
Options
Number of
Sections
Dimensions:
Height, Width, Depth
Weight
Watts
Amps
120 / 240 V AC
Driver #
& Address
BA-3724
4 Total
Top 2
Bottom 2
H 9'-4", W 36'-0", D 6"
(2845 mm, 10973 mm, 152 mm)
H 4'-0", W 18'-0", D 6"
(1219 mm, 5486 mm, 152 mm)
H 5'-4", W 18'-0", D 6"
(1626 mm, 5486 mm, 152 mm)
840 lb
(382 kg)
900 W
7.5 A / 3.75 A
A1 64
A2 65
A3 66
w/TNMC
(same)
(same)
960 lb
(436 kg)
1200 W
10 A / 5 A
TNMC 221
FB-2018
FB-2019
FB-2020
2 Total
Top &
Bottom
H 8'-0", W 18'-0", D 6"
(2438 mm, 5486 mm, 152 mm)
H 4'-0", W 18'-0", D 6"
(1219 mm, 5486 mm, 152 mm)
565 lb
(256 kg)
600 W
5 A / 2.5 A
A1 15
A2 19
w/TNMC
(same)
(same)
645 lb
(293 kg)
900 W
7.5 A / 3.75 A
TNMC 221
w/TNMC +
Electronic
Captions
(same)
(same)
805 lb
(365 kg)
1200 W
10 A / 5 A
Electronic
Captions 227
w/Backlit
Captions
(Top &
Bottom)
(same)
(same)
625 lb
(283 kg)
1500 W
12.5 A
(120 V AC only)
A1 15
A2 19
FB-2021
FB-2022
FB-2023
2 Total
Top &
Bottom
H 8'-0", W 25'-0", D 6"
(2438 mm, 7620 mm, 152 mm)
H 4'-0", W 25-0", D 6"
(1219 mm, 7620 mm, 152 mm)
815 lb
(370 kg)
600 W
5 A / 2.5 A
A1 15
A2 19
w/TNMC
(same)
(same)
935 lb
(424 kg)
900 W
7.5 A / 3.75 A
TNMC 221
w/TNMC +
Electronic
Captions
(same)
(same)
1095 lb
(496 kg)
1200 W
10 A / 5 A
Electronic
Captions 227
w/Backlit
Captions
(Top &
Bottom)
(same)
(same)
875 lb
(396 kg)
1500 W
12.5 A
(120 V AC only)
A1 15
A2 19
FB-2024
2 Total
Top &
Bottom
H 8'-0", W 32'-0", D 6"
(2438 mm, 9754 mm, 152 mm)
H 4'-0", W 32'-0", D 6"
(1219 mm, 9754 mm, 152 mm)
720 lb
(327 kg)
600 W
5 A / 2.5 A
A1 15
A2 19
w/TNMC
(same)
(same)
840 lb
(381 kg)
900 W
7.5 A / 3.75 A
TNMC 221
