Mechanical Installation 6-3
Models without
TNMC
Drawing Titles Number
Structure, Football
A-44556
FB-2001, FB-2004,
SO-2014
Beam and Footing Recommendations, FB-200X
Structure, Football
A-160931
A-44556
FB-2002, FB-2003 Installation Specifications, FB-2002 & FB-2003
Structure, Football
A-128044
A-44556
Models with
TNMC
Drawing Titles Number
FB-1424, FB-1524,
SO-1424, SO-1624
Beam & Footing Recommendations, FB-XX24
Structure, Football
A-44514
A-44556
FB-1430, FB-1530,
FB-1630, FB-1730,
FB-1830, SO-1830,
SO-1930, SO-2030
Beam & Footing Recommendations, FB-XX30
Structure, Football
A-44515
A-44556
FB-2001, FB–2004 Beam and Footing Recommendations, FB-200X
Structure, Football
A-160931
A-44556
FB-1630L, FB-
1830L, SO-1830L
Beam & Footing Recommendations, FB-XX30L
Structure, Football
A-158779
A-44556
FB-2003 Installation Specifications, FB-2002 & FB-2003
Structure, Football
A-128044
A-44556
SO-1930, SO-2030
Beam & Footing Recommendations, FB-XX30
Structure, Football
A-44515
A-44556
Refer to the installation specification drawings listed in the preceding tables for the
rear view of each of the models. These drawings specify the number of beams and
the recommended spacing between them. The drawings also indicate the size of
beams required to support the scoreboard at different heights under various wind
speed conditions. All of the beam specifications illustrate W-shape steel beams
(wide-flange I-beams). The first number indicates the front-to-rear depth of the
beam, and the second number indicates the weight in pounds per foot of length.
Column and footing size dimensions provided with the drawings can help in
estimating installation costs.
