40 TNMC & Electronic Caption Troubleshooting & Maintenance
6.5 Component Locations & Access
Reference Drawings:
Component Locations; 832/848/864 Red/Amb LED, TNMC, G4 ............ Drawing A-257029
Component Loc.; 34mm Red/Amb/Wht LED TNMC G4 .........................Drawing B-975100
Component Loc.; 46mm Red/Amb/Wht LED TNMC G4 .........................Drawing B-975635
Figure 31 illustrates the component locations of an 8x48-34mm display with all modules
removed. This layout will be similar for 8x32-34mm cabinets as well. The 8x64-34mm cabinets
require an additional power supply behind the sixth module. Refer to Drawing B-975100.
Figure 32 illustrates the component locations of an 8x48-46mm display, and this layout will
also be similar for 8x32-46mm cabinets. Note that 8x48-46mm displays featuring white LEDs
require an additional power supply behind the fourth module. Refer to Drawing B-975635.
Figure 31: 8x48-34 Display with Modules Removed
Figure 32: 8x48-46 Display with Modules Removed
