Daktronics FB-2025 - Page 14

8 Mechanical Installation
Model &
Options
Number of
Sections
Dimensions:
Height, Width, Depth
Weight
Watts
Amps
120 / 240 V AC
Driver #
& Address
w/TNMC
(same)
(same)
1060 lb
(481 kg)
900 W
7.5 A / 3.75 A
TNMC 221
w/TNMC +
Electronic
Captions
(same)
(same)
1300 lb
(590 kg)
1200 W
10 A / 5 A
Electronic
Captions 227
T.O.L. 225
w/Backlit
Captions
(Top &
Bottom)
(same)
(same)
1020 lb
(462 kg)
1500 W
12.5 A
(120 V AC only)
A1 15
A2 19
FB-3010
w/TNMC
2 Total
Top &
Bottom
H 8'-0", W 18'-0", D 6"
(2438 mm, 5486 mm, 152 mm)
H 4'-0", W 18'-0", D 6"
(1219 mm, 5486 mm, 152 mm)
600 lb
(272 kg)
1200 W
5 A
(240 V AC only)
A1 1
A2 11
TNMC 221
MS-2009
2 Total
Top
Bottom
H 10’-0”, W 25’-0”, D 6”
(3048 mm, 7620 mm, 152 mm)
H 4’-6”, W 25’-0”, D 6”
(1371 mm, 7620 mm, 152 mm)
H 5’-6”, W 25’-0”, D 6”
(1676 mm, 7620 mm, 152 mm)
770 lb
(349 kg)
600 W
5 A / 2.5 A
A1 71
A2 72
w/TNMC
(same)
(same)
890 lb
(404 kg)
900 W
7.5 A / 3.75 A
TNMC 221
w/TNMC +
Electronic
Captions
(same)
(same)
1130 lb
(513 kg)
1200 W
10 A / 5 A
Electronic
Captions 223
MS-2918
2 Total
Top &
Bottom
H 8’-0”, W 16’-0”, D 6”
(2438 mm, 4877 mm, 152 mm)
H 4’-0”, W 16’-0”, D 6”
(1219 mm, 4877 mm, 152 mm)
480 lb
(218 kg)
600 W
5 A / 2.5 A
A1 71
A2 72
w/TNMC
(same)
(same)
560 lb
(254 kg)
900 W
7.5 A / 3.75 A
TNMC 221
SO-2011
2 Total
Top
Bottom
H 7'-0", W 20'-0", D 6"
(2286 mm, 6096 mm, 152 mm)
H 4'-6", W 20'-0", D 6"
(1372 mm, 6096 mm, 152 mm)
H 3'-0", W 20'-0", D 6"
(914 mm, 6096 mm, 152 mm)
450 lb
(204 kg)
600 W
5 A / 2.5 A
A1 17
A2 11
w/TNMC
(same)
(same)
570 lb
(259 kg)
900 W
7.5 A / 3.75 A
TNMC 221
