EN
Page | 47
Electrical connection
Notes for the electrician
• The appliance is designed for connection to three-phase
and alternating current 380- 415 V 3 N~50 Hz
• The rated voltage of the heating elements is 230 V.
IMPORTANT
For a connection variant other than 3 phases, please contact
8
After Sales Service.
An appropriately designed cable type must be selected as
the mains power cable, taking into account the type of
connection and rated power of the cooker.
The connection cable is fixed in the cable clamp.
Earthing
conductor
Mains power socket open/close
• To unlock, insert a screwdriver (a) and move it slightly
downwards (b).
• To close, fold the cover and snap in with light pressure.
8
After Sales Service +49 2944 9169760
Connect the earthing conductor to the terminal
of the terminal strip marked with .
1 red; 2 E earth; 3 white
Figure 8 Top edge of oven
Neutral conductor symbol
Figure 9
Mains power socket
