dallara F-312 - Wing to Endplate Mounting; Unión Ala - Endplate de Aluminio

F 317
Owners Manual / Manual de Usuario
Euroformula Open Technical Comision
Comisión Técnica del Euroformula Open
64/78
Version 1801 of April 2018
Versión 1801 de Abril de 2018
ONLY be authorized the sensors of the
annexed list
ÚNICAMENTE estarán autorizados los sensores
de la lista anexa.
Listing
PAGE
Apllicab.
Reference
Description
TRIGGER
WHEEL ASS
ALL
09P000040
Sensor - RPM Sensor (white)
TOP PLATE
ASS
ALL
09P000157 x 2
Sensor - Pressure 0-10B with ASL606-05PN
Conn.
2 sensors POIL & PFUEL
CAM COVER
ASS
ALL
09P000158
Sensor - SCAM BOSCH Hall
BLOCK ASS
ALL
09P000183 x 2
Sensor - WATERT/OILT Termistor 2 sensors
OILT & WATERT
PADDLE SHIFT
PNEUMATICS
ALL
09P000199
Sensor - 0-300bar UNF 1/8 with 8T6 Male Plug
conn.
SENSORS DOC
ALL
09P000219
Sensor - LAMBDA (With DTM6P connector)
CLUTCH PRESS
ASS
ALL
09P000222
Sensor - 0-80bar M10x100 (Packard 3w)
THROTTLE
LINKAGE ASS
ALL
09P000272
Sensor - TPS HALL (with Connector) - 0-100º
(with fitted ASU603-03-PA)
GEARBOX ASS
ALL
09P000273
Sensor - GEAR HALL Contactless (with ASL-
606-05PN-HE Connector)
GEARBOX ASS
ALL
09P000274
Part - GEAR D-Shape Sensor Shaft Adapter
INTAKE ASS
NEW
09P000283
Sensor - BOSCH PTAIR (with Connector
ASU603-05PA)
INTAKE ASSi
OLD
09P000154
Sensor - Rear WS01 Modified BOSCH Hall with
150mm cable & ASU connector
Valid until 30/06/2018 / Válido hasta
30/06/2018)
SENSORS DOC
NEW
09P000303
Sensor - Rear WS01 Modified BOSCH Hall with
150mm cable & ASU connector
GEARBOX ASS
NEW
09P000246 x 2
Part - Support Rear - WheelSpeed WS01
(Bosch PickUp)
Wing to endplate mounting
Unión ala – endplate de aluminio
In order to improve the security of the
mounting between the wing and the
aluminium endplate, the use of silicone is
authorized.
Con el objeto de mejorar la seguridad del
montaje entre el ala y el endplate de aluminio,
se autoriza el uso de silicona para.
