DF3000A(-DN) / DF3000AS(-DN)
34Dallmeier electronic
9.4 Pin assignment interfaces
Fig. 9-7
DC auto iris interface for iris control
DC auto iris interface
for iris control
Pin Signal
1 Control -
2 Control +
3 Drive +
4 Drive -
2
3
1
4
