13 Spyder2 4k User’s Manual
03-032-10195-04 DALSA
!
Table 4: DALSA Camera Control Configuration
Signal Configuration Pin
CC1 EXSYNC 9, 22
CC2 PRIN 10, 23
CC3 Spare 11, 24
CC4 Spare 12, 25
See Appendix B for the complete DALSA Camera Link configuration table, and refer to
the DALSA Web site, vfm.dalsa.com, for the official Camera Link documents.
Hirose 6-pin Circular Male
5
4
6
2
3
1
Mating Part: HIROSE
HR10A-7P-6S
Pin Description Pin Description
1 +12 V to +15 V 4 GND
2 +12 V to +15 V 5 GND
3 +12 V to +15 V 6 GND
2.4 Power Supplies
The camera requires a single voltage input (+12 V to +15 V). The camera meets all
performance specifications using standard switching power supplies, although well-
regulated linear supplies provide optimum performance. See the Performance
Specifications for current requirements.
When setting up the camera’s power supplies follow these guidelines:
• Protect the camera with a fast-blow fuse between power supply and camera.
• Do not use the shield on a multi-conductor cable for ground.
• Keep leads as short as possible to reduce voltage drop.
See section 1.3 for power requirements.
WARNING: It is extremely important that you apply the appropriate voltages to your camera.
Incorrect voltages will damage the camera. Protect the camera with a fast-blow fuse between
power supply and camera.
Visit http://vfm.dalsa.com for a list of companies that make power supplies that meet
the camera’s requirements. The companies listed should not be considered the only
choices. Many high quality supplies are available from other vendors. DALSA assumes
no responsibility for the use of these supplies.
2.5 Control Inputs, Camera Link
The camera accepts control inputs through the Camera Link MDR26F connector. All inputs
are optional. The camera ships in exposure mode 2 (programmable line rate and exposure time).
All Camera Control (CCx) signals are in a logic HIGH state.
Line rate can be set internally using
