41 Spyder2 4k User’s Manual
03-032-10195-04 DALSA
Figure 5: Mechanical Dimensions
WITH F MOUNT
WITHLARGE FORMAT
ADAPTER
62.3
89.2
Ø78.0
M72X0.75
CONT ROL
DATA 1
STATUS
POWER
10.5
25.0
54.9(2X)
All units in mm.
32.5
85.0
78.0 (2X)
58.0 (2X)
85.0
46.81 (2X)
46.81 (2X)
3.5(2X) 9.1 (2X)
65.0
M3x0.5 - 6H (4X)
7.0 DEEP
M2x0.4 - 6H(4X)
7.0 DEEP
3.5(2X)
19.1 (2X)
49.3
70.0 (2X)
7.5 (2X)
6.0 (4X)
53.7
M3x0.5 - 6H (4X)
5.0 DEEP
OPTICAL DIS
TANCE
6.56±0.25 CAMERA SURFACE TO DIE SURFACE
NO MOUNT
