62 Spyder2 4k User’s Manual
03-032-10195-04 DALSA
Error Codes
Cod
e
Description Suggested Cause
9 Start value must be an odd
number less than the even
numbered end value
roi: invalid starting or ending pixel index
10 Camera memory check failure Memory test of external RAM failed
11 Unable to configure DSP DSP (FPGA) configuration failure
12 DSP configuration reset failure DSP (FPGA) could not be placed in
configuration mode
13 Get line process command timed
out, check for the presence of
external signals
gl,gla,cao,cag,ccf,ccp timed out.
Current exposure mode requires external
SYNC, however SYNC signal not present
14 DSP echo test error DISC bus communication test failure
15 Invalid sensor configuration
(DSP)
Invalid sensor configuration read from DSP
(FPGA)
16 Invalid sensor configuration
(ADC)
Invalid sensor configuration encoding on
the board
17 Sensor configuration mismatch Sensor configuration read from DSP is
different than one encoded on the board
18 One (or more) of the supply
voltages is out of specification
vv command result
19 The camera's temperature is
outside the specified operating
range
vt command result
20 Not Used Not Used
21 Analog offset calibration failure Analog offset calibration failure (could not
tune the analog offset to obtain targeted
video level)
22 Analog gain calibration failure Analog gain calibration failure (could not
tune the analog gain to obtain targeted
video level)
23 CRC check failure while
attempting to restore the camera
settings
Camera setting will initialize to default
settings, since restore of USER/FACTORY
settings failed (internal micro EE memory
failure). Contact your DALSA
representative or Product Support if this
error code is returned.
24 Camera settings not saved rus, rfs attempted but settings were not
saved. Contact your DALSA representative
or Product Support if this error code is
returned.
25 Pixel coefficients write failure Failure while writing pixel coefficients to
EEROM (I2C EEROM external to micro)
26 I2C communication fault while
accessing temperature sensor
Serial communication fault (I2C) while
accessing temperature sensor
27 Timeout waiting for DISC SYNC
to go LOW
Internal communication protocol error
28 Unable to calibrate gain. Tap Analog gain could not be calibrated because
