Type Depending on the filter type used, 1 to 4
bands may be required for each filter.
The following table lists the available types,
their corresponding parameters and the
number of filter bands required for the selected
type.
Type Param. 1 Param. 2 Param. 3 Param. 4 Param. 5 No. of filters
PEQ
(Parametric EQ)
FRQ Q (and
corresponding
bandwidth - BW)
Gain 1
Notch FRQ Q (and
corresponding
bandwidth - BW)
1
HiShlv FRQ Slope Gain 2
LoShlv FRQ Slope Gain 2
Asym
(Asymmetric filter)
FRQ 1 Slope 1 Gain FRQ 2 Slope 2 4
Parameter ranges and resolutions:
Type
The available filter types.
FRQ Filter frequency (center/corner frequency),
adjustable from 20 Hz to 20 kHz.
On the top right of the «Frequency/FRQ» input
field, the increment is displayed as an octave
value. When you tap the field for the first time,
the frequency increment is set to 1/6 octave.
When you tap the field again, you can toggle
between 1/6 and 1/96 octave increments.
To confirm the set frequency, press the
encoder.
Q
BW
Q of the filter, adjustable from 0.5 ... 25 in
10 % steps.
In addition, the resulting bandwidth (BW) is
displayed as a value (2.0 ... 0.04 octaves) in
a non-editable Information field below the Q
Input field.
Slope
Slope can be set to 6, 12, 18 or
24 dB/octave.
Gain Gain, adjustable from –18 dB to +12 dB in
0.2 dB steps.
Clear
band
Resets all settings of the selected filter band
right away.
d&b D80 Manual 1.8 en54
