15.2. Error messages
The following table lists possible error messages appearing on the
display.
Id Error text Eventlog text Description Location Possible reasons
10 System error 8 System error 8 (%02Xh,
%d)
Unexpected CPU reset DSP Software or hardware
error
11 System error 128 System error 128
(%02Xh, %d)
Internal I
2
C
communication fault
DSP
Any I
2
C device defect
15 Unknown device type Unknown device type Unknown device type
16 Invalid device ident Invalid device ident %d Invalid hardware
configuration
ADDAC, Amp., SMPS Missing or wrong
module identification
17 Invalid CPLD version Invalid CPLD version %d
(minimum required %d)
Invalid CPLD
identification
DSP Missing or wrong CPLD
identification
18 Invalid ADDAC ident Invalid ADDAC board
ident %d
Invalid ADDAC
identification
ADDAC Missing or wrong
ADDAC identification
19 Invalid display ident Invalid display board
ident %d
Invalid DISPLAY
identification
DISPLAY Missing or wrong
DISPLAY identification
20 Program error %u Program error %d, %d,
%d, %d
Program error DSP Various
21 Invalid DSP Data Invalid DSP database
(Position %d, Error %d)
Invalid DSP data DSP Software error
25 Program error %u Program error %d: AWL
error %d in AWL %d,
line %d
Program error DSP Various
28 SMPS comm. error SMPS communication
error (status %04X)
SMPS communication
fault
DSP, SMPS DSP or SMPS defect,
cable defect
29 SMPS firmware
mismatch
SMPS firmware V%d.
%02d.%02d not suitable
for hardware ident %d
Invalid SMPS
configuration
SMPS SMPS firmware does not
match module
identification
30 SMPS temp err %d°C SMPS temperature error
%+3d°C (power %uw)
Temp-Off
31 SMPS overtemp %d°C SMPS overtemperature
%+3d°C (power %uw)
SMPS overtemperature SMPS Poor cooling
32 Mains overvoltage %dV Mains overvoltage (avg
%3dV, peak %3dV,
status %04X, err %04X)
Mains overvoltage (External: Mains) Mains voltage is/was
too high
34 Mains undervoltage
%dV
Mains undervoltage
(avg %3dV, peak %3dV,
status %04X, err %04X)
Mains undervoltage (External: Mains) Mains voltage is/was
too low
35 SMPS error POK SMPS error POK:
timeout while waiting for
power-ok signal %ums
(PSF %4.1uV, avg
%5.1dV)
SMPS startup timeout
SMPS SMPS defect
36 SMPS restart error SMPS error: too many
restarts (restart count
%d)
SMPS restart fault SMPS SMPS defect
