Single Coil - continued R-W Code 1 2 3 4 5 6 7 8 9 Min. Max. Fac. Actual
Display of temperature
1= u56 air temperature
2= u36 product temperature
1-2 o97 1 1 1 1 1 1 1 1 1 1 2 1
Light and night blinds defined
0: Light is switched off and night blind is opened when
the main switch is off
1: Light and night blind is independent of main switch
1-2 o98 1 1 1 1 1 1 1 1 0 1 0
Configuration of alarm relay
The alarm relay will be activated by an alarm in one or
more of the following priorities.
Setting:
0 = The relay is not activated by alarms
1 = Only high priority alarms
2 = High priority and intermediate priority alarms
3 = High priority, intermediate priority and low priority
1-2 P41 1 1 1 1 1 1 1 1 1 0 3 2
Max. opening time of night blinds after a manual
override with DI activation.
1-2 P60 1 0 min. 60 min. 5
Stop time for fans while the night blinds roll down 1-2 P65 1 0 sec 300 sec 0
Cycle time for rail heat at PWM on AO1 1-2 P82 1 1 1 1 1 1 1 1 1 4 sec 60 sec 10
User defined refrigerant 3-digit Rfg. factor K1 1-3* P83 1 1 1 1 1 1 1 1 1 -999 999 300
User defined refrigerant 3-digit Rfg. factor K2 1-3* P84 1 1 1 1 1 1 1 1 1 -999 999 300
User defined refrigerant 3-digit Rfg. factor K3 1-3* P85 1 1 1 1 1 1 1 1 1 -999 999 300
Max. limitation of the superheat reference when
regulated with liquid-filled evaporator
1-2 P86 1 1 1 1 1 1 1 1 1 "P87" 20°C 3
Min. limitation of the superheat reference when
regulated with liquid-filled evaporator
1-2 P87 1 1 1 1 1 1 1 1 1 0°C "P86" 1
Access code 1 (simple access) 1-1 P88 1 1 1 1 1 1 1 1 1 0 999 0
Locking the display control. 0/Off=operation. 1/
On=locked
1-2 P89 1 1 1 1 1 1 1 1 1 0/Off 1/On 0/Off
Configuration of relay output DO2: 0=not used, 1=fan,
2=fan Eco, 3=defrost, 4=rail heat, 5=alarm, 6=light,
7=night blinds, 8=compressor, 9=compressor 2,
10=heating element
1-3* q02 1 0 10 5
Configuration of relay output DO3: 0=not used, 1=fan,
2=fan Eco, 3=defrost, 4=rail heat, 5=alarm, 6=light,
7=night blinds, 8=compressor, 9=compressor 2,
10=heating element
1-3* q03 1 0 10 8
Configuration of relay output DO4: 0=not used, 1=fan,
2=fan Eco, 3=defrost, 4=rail heat, 5=alarm, 6=light,
7=night blinds, 8=compressor, 9=compressor 2,
10=heating element
1-3* q04 1 0 10 9
Configuration of relay output DO5: 0=not used, 1=fan,
2=fan Eco, 3=defrost, 4=rail heat, 5=alarm, 6=light,
7=night blinds, 8=compressor, 9=compressor 2,
10=heating element
1-3* q05 1 0 10 3
Configuration of relay output DO6: 0=not used, 1=fan,
2=fan Eco, 3=defrost, 4=rail heat, 5=alarm, 6=light,
7=night blinds, 8=compressor, 9=compressor 2,
10=heating element
1-3* q06 1 0 10 1
Configuration of analogue output AO1: 0=not used.
1=rail heat PWM
1-3* q09 1 1 1 1 1 1 1 1 1 0 1 0
Manual control of output: AKV valve 0-100% 1-2** q11 1 1 1 1 1 1 1 1 1 0 % 100 % 0
Manual control of output: Compressor1/LLSV 1-2** q12 1 1 1 1 0/Off 1/On 0/Off
Manual control of output: Fan 1-2** q13 1 1 1 1 1 1 1 1 1 0/Off 1/On 0/Off
Manual control of output: Defrost 1-2** q14 1 1 1 1 1 1 1 1 0/Off 1/On 0/Off
Manual control of output: Rail heat 1-2** q15 1 1 1 1 1 0/Off 1/On 0/Off
Manual control of output: Alarm 1-2** q16 1 1 1 1 1 0/Off 1/On 0/Off
Manual control of output: Light 1-2** q17 1 1 1 1 1 1 1 1 0/Off 1/On 0/Off
Manual control of output: Valve in suction line 1-2** q18 1 0/Off 1/On 0/Off
Manual control of output: Compressor 2 1-2** q19 1 0/Off 1/On 0/Off
Manual control of output: Hot gas valve 1-2** q20 1 0/Off 1/On 0/Off
Manual control of output: Night blinds 1-2** q21 1 0/Off 1/On 0/Off
