TERMINALS
EARTH
130BA450.10
Illustration 3.54 Position of Earth Terminals IP00, Enclosure
Type D
130BA455.10
M10 19 NM (14 FT -LB)
T2 97
W/T3 98
EARTH
TERMINALS
Illustration 3.55 Position of Earth Terminals IP21 (NEMA type
1) and IP54 (NEMA type 12)
NOTICE
D2 and D4 shown as examples. D1 and D3 are
equivalent.
How to Install
VLT
®
Automation Drive FC 300 Operating Instructions
MG33U402 - Rev. 2013-12-16 47
3 3
