4.1.1 How to Programme on the Numerical
Local Control Panel
The following instructions are valid for the numerical LCP
(LCP 101):
The control panel is divided into 4 functional groups:
1. Numerical display.
2. Menu keys and indicator lights - changing
parameters and switching between display
functions.
3. Navigation keys and indicator lights (LEDs).
4. Operation keys and indicator lights (LEDs).
