1 Install the safety option
3 Commission
2 Setup parameters
Illustration 9: Installation and Commissioning Overview
4.3 Installing the Option
Context:
N O T I C E
Place the VLT® AutomationDrive FC 302 with safety option (including connection between S37 (Y30/12 or Y31/12) on VLT®
Safety Option MCB 152 and X44/12 on the control card) in an IP54 enclosure as per IEC 60529.
Installation
Installation Guide | VLT®Safety Option MCB 152
AN327351953089en-000101 / 130R0578| 21
Danfoss A/S © 2020.02
