9.3.3 Digital In/Out 5-**

Par.

No. #

Parameter description Default value 4-set-up FC 302

only

Change

during

operation

Conver-

sion

index

Type

5-0* Digital I/O mode

5-00 Digital I/O Mode [0] PNP All set-ups FALSE - Uint8

5-01 Terminal 27 Mode [0] Input All set-ups TRUE - Uint8

5-02 Terminal 29 Mode [0] Input All set-ups x TRUE - Uint8

5-1* Digital Inputs

5-10 Terminal 18 Digital Input [8] Start All set-ups TRUE - Uint8

5-11 Terminal 19 Digital Input [0] No operation All set-ups TRUE - Uint8

5-12 Terminal 27 Digital Input [0] No operation All set-ups TRUE - Uint8

5-13 Terminal 29 Digital Input [0] No operation All set-ups TRUE - Uint8

5-14 Terminal 32 Digital Input [90] AC Contactor All set-ups TRUE - Uint8

5-15 Terminal 33 Digital Input [91] DC Contactor All set-ups TRUE - Uint8

5-16 Terminal X30/2 Digital Input [0] No operation All set-ups TRUE - Uint8

5-17 Terminal X30/3 Digital Input [0] No operation All set-ups TRUE - Uint8

5-18 Terminal X30/4 Digital Input [0] No operation All set-ups TRUE - Uint8

5-19 Terminal 37 Safe Stop [1] Safe Stop Alarm 1 set-up TRUE - Uint8

5-3* Digital Outputs

5-30 Terminal 27 Digital Output [0] No operation All set-ups TRUE - Uint8

5-31 Terminal 29 Digital Output [0] No operation All set-ups x TRUE - Uint8

5-4* Relays

5-40 Function Relay [0] No operation All set-ups TRUE - Uint8

5-41 On Delay, Relay 0.30 s All set-ups TRUE -2 Uint16

5-42 O Delay, Relay 0.30 s All set-ups TRUE -2 Uint16

Appendix A - Parameters

VLT

AutomationDrive FC 302 Low Harmonic Drive

132–630 kW
