Table 134: MCCB Part Numbers for VLT
®
AutomationDrive FC 302 Enclosed Drive Models N90K–N250, 525–690 V
N90K
N110
N132
N160
N200
N250
IEC
400 A/690 V
400 A/690 V
400 A/690 V
630 A/690 V
630 A/690 V
630 A/690 V
ABB P/N
T5L400T
T5L400T
T5L400T
T6L630T
T6L630T
T6L630T
UL
400 A/600 V
400 A/600 V
400 A/600 V
600 A/600 V
600 A/600 V
600 A/600 V
ABB P/N
T5L400TW
T5L400TW
T5L400TW
T6L600TW
T6L600TW
T6L600TW
Table 135: MCCB Part Numbers for VLT
®
AutomationDrive FC 302 Enclosed Drive Models N315–N560, 525–690 V
N315
N355
N400
N500
N560
IEC
600 A/690 V
1000 A/690 V
1000 A/690 V
1000 A/690 V
1000 A/690 V
ABB P/N
T6L630T
T7L1000LSPR23 1 DS-
LS
T7L1000LSPR23 1 DS-
LS
T7L1000LSPR23 1 DS-
LS
T7L1000LSPR23 1 DS-
LS
UL
600 A/600 V
1000 A/600 V
1000 A/600 V
1200 A/600 V
1200 A/600 V
ABB P/N
T6LQ600TW
T7L1000PR231/P
T7L1000PR231/P
T7L1200PR231/ P
T7L1200PR231/ P
Table 136: MCCB Part Numbers for VLT
®
AutomationDrive FC 302 Enclosed Drive Models N630–N710, 525–690 V
N630
N710
IEC
1250 A/690 V
1250 A/690 V
ABB P/N
T7L1250LSPR23 1 DS-LS
T7L1250LSPR23 1 DS-LS
UL
1200 A/600 V
1200 A/600 V
ABB P/N
T7L1200PR231/ P
T7L1200PR231/ P
10.9 Enclosure Dimensions
10.9.1 Pedestal Dimensions
The pedestal, on which the enclosure sits, is available in 3 different heights:
100 mm (3.9 in)
200 mm (7.9 in)
400 mm (15.8 in)
AQ262139143212en-000301 / 130R0879 | 185Danfoss A/S © 2021.10
Specifications
VLT® AutomationDrive FC 302
Operating Guide

Danfoss D9h Specifications
