1.
2.
3.
Illustration 57: Connection Points for Mains to Input Power Option (Enclosed Drive Configured With Power Options Cabinet)
Factory cables connecting contactor to drive input
terminals
Input power terminals (disconnect option is shown)
5.8.3 Connecting the Drive Module to the Motor
Procedure
Strip a section of the outer cable insulation.
Fasten a connector/cable lug to the end of the stripped cable.
Create an electrical connection between the cable shield and ground by securing the stripped wire under the cable clamp.
AQ262139143212en-000301 / 130R0879102 | Danfoss A/S © 2021.10
Electrical Installation
VLT® AutomationDrive FC 302
Operating Guide
