Table 13: Mains Option Codes
Character position
Code
Description
16–17
MX
None
M1
Fusible disconnect
M2
Non-fusible disconnect
M3
Circuit breaker (MCCB)
M4
Mains contactor
M5
AC reactor
M6
Fuses
MA
Fusible disconnect + mains contactor
MB
Non-fusible disconnect + mains contactor
MC
AC reactor + fusible disconnect
MD
AC reactor + fusible disconnect + mains contactor
ME
AC reactor + non-fusible disconnect
MF
AC reactor + circuit breaker (MCCB)
MG
AC reactor + mains contactor
MH
AC reactor + non-fusible disconnect + mains contactor
Table 14: Output Filter Codes
Character position
Code
Description
18
X
None
D
dU/dt filter
S
Sine-wave filter
C
Common-mode filter
1
Common-mode + dU/dt filters
2
Common-mode + sine-wave filters
Table 15: Reserved Code
Character position
Code
Description
19
X
None
AQ262139143212en-000301 / 130R087926 | Danfoss A/S © 2021.10
Product Overview
VLT® AutomationDrive FC 302
Operating Guide
