e30bu860.10

U, V, W

U/T1, V/T2, W/T3

Illustration 26: Cable Routing for dU/dt Cabinet with Top Exit to E5h or E6h Drive Cabinet

AQ262139143212en-000301 / 130R087960 | Danfoss A/S © 2021.10

Electrical Installation

VLT® AutomationDrive FC 302

Operating Guide
