Danfoss D9h - Page 77

e30bu182.10
U
W
V
1
Illustration 43: Split Shipment Electrical Connections (Top Exit Cabinet)
1
Motor cables (U/V/W) to motor terminals (U/V/W) in drive cabinet
AQ262139143212en-000301 / 130R0879 | 77Danfoss A/S © 2021.10
Electrical Installation
VLT® AutomationDrive FC 302
Operating Guide
