Danfoss D9h

Option card terminal
Corresponding terminal within the control compartment
X57.9
XDW.35
X57.10
XDW.36
X58.1
XDW.25
X58.2
XDW.26
X59.1
XDW.37
X59.2
XDW.38
X59.3
XDW.39
X59.4
XDW.40
X59.5
XDW.41
X59.6
XDW.42
X59.7
XDW.43
X59.8
XDW.44
Table 52: Option C0 Terminal Connections for VLT® Positioning Controller MCO 351
Option card terminal
Corresponding terminal within the control compartment
X55.1
XDW.1
X55.2
XDW.2
X55.3
XDW.3
X55.4
XDW.4
X55.5
XDW.5
X55.6
XDW.6
X55.7
XDW.7
X55.8
XDW.8
X55.9
XDW.9
X55.10
XDW.10
X55.11
XDW.11
X55.12
XDW.12
X56.1
XDW.13
X56.2
XDW.14
X56.3
XDW.15
X56.4
XDW.16
X56.5
XDW.17
X56.6
XDW.18
AQ262139143212en-000301 / 130R0879 | 87Danfoss A/S © 2021.10
Electrical Installation
VLT® AutomationDrive FC 302
Operating Guide
