| 3DKRCE.PI.RL0.G7.ML
Installation Guide | ERC 213
Electrical Connections
DO1
12
SairS5Sc/DI
1D
I2
DO2 DO3
GN
DG
ND
3L 4N 567891011121
31
4
~~~~
Sair
Sc
DI1
DI2
DO2
DO3
DO1
S5
Power supply
(according to the product code number)
Connectors:
Max. Torque = 0.4 Nm
Quick programming tool: EKA 183B
