Danfoss ERC 213 User Guide

Figure 3: ERC 214
Sair
Sc
DI1
DI2
DO4
DO2
DO3
DO1
S5
Danfoss 80G8379
Outputs:
• Relay 1: compressor/solenoid valve control
• Relay 2: defrost control, external alarm or cabinet light
• Relay 3: fan control
• Relay 4: this can be congured for either cabinet light or external alarm
Inputs:
• Input 1: control sensor (Sair)
• Input 2: defrost sensor (S5)
• Input 3: condenser sensor (Sc) or digital input that can be congured for various functions as metioned under
menu code o02
• Input4: digital input that can be congured for various functions as mentioned under menu code o37
© Danfoss | Climate Solutions | 2023.01 BC194286421698en-000901 | 7
Electronic refrigeration control, type ERC 21X

Danfoss ERC 213 Specifications

General

Supply Voltage	230 V AC
Dimensions	75 x 33 x 85 mm
Digital Inputs	2
Enclosure Rating	IP20
Input Voltage	230 V AC
Housing Material	Plastic
Application	Refrigeration
Storage Temperature	-20 - 70 °C
Relative Humidity	20% to 80% non-condensing
Protection Class	Class II
Weight	0.2 kg
Operating Temperature	-10°C to +50°C
Power Consumption	3 W
