List of Parameters
Range/number
Function of settings Factory setting Parameter No.
Preset reference 1 -100.00 % - +100.00 % 0.00 % Parameter 215
Preset reference 2 -100.00 % - +100.00 % 0.00 % Parameter 216
Catch up/slow down value 0.00 - 100.00 % 0.00 % Parameter 219
Current limit for motor mode Min.- max. limit in % of I
RATED
Max. limit Parameter 221
Frequency bypass, bandwidth 0 (off) - 100 % 0 % Parameter 229
Frequency bypass 1 0.0 - 132 Hz 0.0 Hz Parameter 230
Frequency bypass 2 0.0 - 132 Hz 0.0 Hz Parameter 231
Time out 1 -99 sec. 10 sec. Parameter 317
Function after time out Off/Stop and trip Off Parameter 318
Pulse reference/feedback, max. freq.100 - 70000 Hz 5000 Hz Parameter 327
Terminal 1, analog input current 3 No operation Parameter 331
Terminal 2, digital input 25 Reference Parameter 332
Terminal 3, digital input 25 Reset Parameter 333
Terminal 4, digital input 24 Start Parameter 334
Terminal 5, digital input 23 Jog Parameter 335
Terminal 1, min. scaling 0.0 - 20.0 mA 0.0 mA Parameter 336
Terminal 1, max. scaling 0.0 - 20.0 mA 20.0 mA Parameter 337
Terminal 2, min. scaling 0.0 - 10.0 V 0.0 V Parameter 338
Terminal 2, max. scaling 0.0 - 10.0 V 10.0 V Parameter 339
Output functions 21 No operation Parameter 340
Brake function Off/AC braking Off Parameter 400
Reset function 11 Manual reset Parameter 405
Switching frequency 1.5 - 14.0kHz Unit dependent Parameter 411
Variable switching frequency 3 Temp. dep. sw. freq. Parameter 412
Overmodulation function Off/On On Parameter 413
Minimum feedback -100000 - FB
HIGH
0 Parameter 414
Maximum feedback FB
LOW
- 100,000 1500 Parameter 415
Reference/feedback unit 42 % Parameter 416
Process PID normal/inverse ctrl. Normal/inverse Normal Parameter 437
Process PID anti windup Disable/Enable Enable Parameter 438
Process PID start frequency f
MIN
- f
MAX
f
MIN
Parameter 439
Process PID proportional gain 0.00 (off) - 10.00 0.01 Parameter 440
Process PID integral time 0.01 - 9999 sec. (off) 9999 sec. Parameter 441
Process PID differentation time 0.00 (off) - 10.00 sec. 0.00 sec. Parameter 442
Process PID different. gain limit 5 -50 5 Parameter 443
Process PID lowpass filter time 0.1 - 10.00 sec. 0.1 sec. Parameter 444
Flying start 4 Disable Parameter 445
Switching pattern 2 SFAVM Parameter 446
Bus address 1 - 126 1 Parameter 500
Baudrate 300 - 9600 Baud/6 9600 Baud Parameter 501
Coasting 4 Logic or Parameter 502
Quick-stop 4 Logic or Parameter 503
DC-brake 4 Logic or Parameter 504
Start 4 Logic or Parameter 505
Reversing 4 Logic or Parameter 506
Selection of setup 4 Logic or Parameter 507
Selection of speed 4 Logic or Parameter 508
Bus jog 1 0.0 - f
MAX
10.0 Hz Parameter 509
Bus jog 2 0.0 - f
MAX
10.0 Hz Parameter 510
Telegram profile Profidrive/FC Drive FC Drive Parameter 512
Bus time interval 1 sec. Parameter 513
Bus time interval function 6 Off Parameter 514
