FCM 300 Series
MG.03.B6.02 - VLT is a registered Danfoss trademark32
Changing data
Regardless of whether a parameter has been
selected under the Quick menu or the Menu mode,
the procedure for changing data is the same.
Pressing the [CHANGE DATA] key gives access to
changing the selected parameter, following which the
underlining in line 4 will flash on the display.
The procedure for changing data depends on
whether the selected parameter represents a
numerical data value or a text value.
Changing a text value
If the selected parameter is a text value, the text value
is changed by means of the [+/-] keys.
The bottom display line shows the text value that will
be entered (saved) when acknowledgement is given
[OK].
FREQUENCY
50.0 HZ
001 LANGUAGE
ENGLISH
Menu mode
The Menu mode is started by pressing the [MENU]
key, which produces the following read-out on the
display:
Line 3 on the display shows the parameter group
number and name.
Parameter groups
In the Menu mode the parameters are divided into
groups. Selection of parameter group is effected by
means of the [<>] keys.
The following parameter groups are accessible:
Group no. Parameter group:
0 Operation & Display
1 Load & Motor
2 References & Limits
3 Inputs & Outputs
4 Special functions
5 Serial communication
6 Technical functions
*For information on parameter group 800 and 900 for
PROFIBUS, please see the FCM Profibus manual
MG.03.EX.YY.
When the desired parameter group has been
selected, each parameter can be chosen by means of
the [+/-] keys:
The 3rd line of the display shows the parameter
number and name, while the status/value of the
selected parameter is shown in line 4.
FREQUENCY
001 LANGUAGE
50.0 HZ
ENGLISH
50.0 HZ
FREQUENCY
0..
KEYB. & DISPLAY
Local Control
