MG.03.B6.02 - VLT is a registered Danfoss trademark40
✭ = factory setting. ( ) = display text [ ] = value for use in communication via serial communication port
007 LCP copy (LCP COPY)
Settings:
✭ No copying (NO COPY) [0]
Upload all parameters (UPLOAD ALL PARAM) [1]
Download all parameters (DOWNLOAD ALL) [2]
Download power-independent par.
(DOWNLOAD SIZE INDEP.) [3]
Function:
Parameter 007 is used if it is desired to use the
integrated copying function of the control panel. You
can therefore easily copy parameter value(s) from one
FC motor to another.
Description of choice:
Select Upload all parameters [1] if all parameter
values are to be transmitted to the control panel.
Select Download all parameters [2] if all transmitted
parameter values are to be copied to the FC motor on
which the control panel has been mounted.
Select Download power-independent par. [3] if only
the power-independent parameters are to be
downloaded. This is used if downloading to a FC
motor that has a different rated power than the one
from where the parameter Setup originates.
NB!
Uploading/Downloading can only be carried
out in the Stop mode and only between units
with the same
major
database version (see par. 626 value
major.minor)
008 Display scaling of motor frequency
(FREQUENCY SCALE)
Settings:
0.01 - 100.00 [1 - 10000]
✭ 1.00 [100]
Function:
This parameter chooses the factor to be multiplied
by the motor frequency, f
M
, for presentation in the
display, when parameters 009-012 have been set for
Frequency x Scaling [5].
Description of choice:
Set the desired scaling factor.
009 Display line 2 (DISPLAY LINE 2)
Settings:
None [0]
Reference [%] (REFERENCE [%]) [1]
Reference [unit] (REFERENCE [UNIT]) [2]
Feedback [unit] (FEEDBACK [UNIT]) [3]
✭ Frequency [Hz] (FREQUENCY [Hz]) [4]
Frequency x Scaling [-] (FREQUENCY X SCALE)[5]
Motor current [A] (MOTOR CURRENT [A]) [6]
Torque [%] (TORQUE [%]) [7]
Power [kW] (POWER [kW]) [8]
Power [HP] (POWER [hp] [US]) [9]
Motor voltage [V] (MOTOR VOLTAGE [V]) [11]
DC link voltage [V] (DC LINK VOLTAGE [V]) [12]
Thermal load, FC [%] (FC THERMAL [%]) [14]
Hours run [Hours] (RUNNING HOURS) [15]
Digital input [Binary code] (DIGITAL INPUT [BIN])[16]
External reference [%] (EXTERNAL REF [%]) [21]
Status word [Hex] (STATUS WORD [HEX]) [22]
Heat sink temp. [°C] (HEATSINK TEMP [°C]) [25]
Alarm word [Hex] (ALARM WORD [HEX]) [26]
Control word [Hex] (CONTROL WORD [HEX]) [27]
Warning word 1 [Hex]
(WARNING WORD 1 [HEX]) [28]
Warning word 2 [Hex]
(WARNING WORD 2 [HEX]) [29]
Analog input 1 [mA] (ANALOG INPUT 1 [mA]) [30]
Analog input 2 [V] (ANALOG INPUT 2 [V]) [31]
Function:
This parameter allows a choice of the data value to
be displayed in line 2 of the display.
Parameters 010-012 enable the use of three
additional data values to be displayed in line 1.
NB!
In parameter 009, "none" [0] cannot be
selected.
Description of choice:
ReferenceReference
ReferenceReference
Reference
[%] [%]
[%] [%]
[%] corresponds to the total reference (sum
of digital/analogue/preset/bus/freeze ref./catch-up
and slow-down).
Reference Reference
Reference Reference
Reference
[unit][unit]
[unit][unit]
[unit] gives the sum of the references
using the unit stated on the basis of configuration in
parameter 100 (Hz, Hz and rpm).
FeedbackFeedback
FeedbackFeedback
Feedback
[unit] [unit]
[unit] [unit]
[unit] gives the status value of terminal 1
and 2 using the unit/scale selected in parameter 414,
415 and 416.
FrequencyFrequency
FrequencyFrequency
Frequency
[Hz] [Hz]
[Hz] [Hz]
[Hz] gives the motor frequency, i.e. the
output frequency to the motor.
Operation & Display
