■ Danfoss PC software for serial communication
Using serial communication makes it possible to
monitor, programme and control one or several FC
motors from a centrally placed computer. All FCM 300
Series have an RS 485 port as standard, which
enables them to communicate e.g. with a PC. A
programme entitled VLT
®
Software Dialog is available
for this purpose.
VLT
®
Software Dialog comes in three modules and -
as a minimum - contains the programmes included in
the Basic module.
The Basic module covers:
TEST RUN
is used for controlling and commissioning
of a FC motor, including:
- setting of reference value,
- simultaneous display of selected
parameters in graphs,
- option of DDE link, e.g. to a
spreadsheet.
PARAMETER SETUP
is used for setting up and transferring
parameter sets, including:
- setting of FC motor parameters,
- parameter sets can be obtained from
and copied to a FC motor,
- documentation/print-out of the Setup
including diagrams.
BUS ADDRESS SETUP
is used for setting the bus addresses on
individual FC motors which are connected
to the same bus.
- setting bus addresses
- storing list of units
- reporting list of units
The Logging module covers:
LOGGING
is used for collecting and displaying historical
or real-time operating data:
- graphical representation of selected
parameters from several FC motors,
- collection of log data to file,
- option of DDE link e.g. to a spreadsheet.
MODEM SETUP
is used for setting up the modem.
- sets the FC motor modem via the
communication port of the PC.
The template module covers:
TEMPLATE SETUP
is used for setting up template files for
PARAMETER SETUP:
- the template file functions as a mask that
limits the number of accessible
parameters when a parameter file is to be
made or edited in PARAMETER SETUP,
- the template file may contain preset
values for the parameters of the FC motor.
NB!
The logging and template module calls for a
Basic module to be installed on the same
PC.
The guided tour covers:
GUIDED TOUR
offers a demonstration of the VLT Software
Dialog programme.
