Fastener size and torque chart
Item Fastener Wrench size Torque
D015 Neutral adjust screw 4 mm internal hex NA
D050 Control coil mounting screw 4 mm internal hex 8 N•m [5.9 lbf•ft]
D060 Neutral adjust locking nut 13 mm hex 10 N•m [7 lbf•ft]
D200 Swash plate feedback pin (not shown) 13 mm hex 25 N•m [18.4 lbf•ft]
D250 Electric control mounting screw 5 mm internal hex 13 N•m [9.5 lbf•ft]
E350 Servo cylinder locking screw 10 mm hex 14.5 N•m [11 lbf•ft]
G10 Control cutoff valve 1 1/16 in hex 45 N•m [33 lbf•ft]
G10B Control cutoff valve coil nut 24 mm hex 10 N•m [7.5 lbf•ft]
K007 Charge check / HPRV 8 mm internal hex 80 N•m [60 lbf•ft]
K350 A pad cover mounting screw 17 mm hex 64 N•m [47 lbf•ft]
B pad cover mounting screw 18 mm hex 76 N•m [56 lbf•ft]
L010 Pressure limiter adjust screw 8 mm internal hex NA
L300/L400/
L101/L201
Pressure limiter cartridge 14 mm hex 30 N•m [22 lbf•ft]
L024 Pressure limiter locking nut 14 mm hex 20 N•m [15 lbf•ft]
L100/L200/
L101/L201
High pressure relief valve 22 mm hex 70 N•m [52 lbf•ft]
V10-1 Charge relief valve 27 mm hex 52 N•m [38 lbf•ft]
V10-2 Charge relief valve 1 in hex 52 N•m [38 lbf•ft]
V10-3 Charge relief valve 24 mm hex 52 N•m [38 lbf•ft]
V020 Charge pressure adjusting screw 6 mm internal hex
NA
V022 Charge pressure locking nut 19 mm hex 40 N•m [30 lbf•ft]
Plug size and torque chart
Item O-ring plug Wrench size Torque
B015 7/16 - 20 3/16 internal hex 20 N•m [15 lbf•ft]
B020 (45/53) 1-1/16 - 12 9/16 internal hex 48 N•m [35 lbf•ft]
B020 (60/68) 1-3/8 - 12 5/8 internal hex 148 N•m [109 lbf•ft]
D065 7/16 - 20 3/16 internal hex 12 N•m [9 lbf•ft]
G250 9/16 - 18 1/4 internal hex
(hardened plug)
45 N•m [33 lbf•ft]
Service Manual
H1 45/53/60/68 Tandem Closed Circuit Axial Piston Pumps
Torque chart
66 |
©
Danfoss | June 2018 520L0928 | AX00000103en-US0303
