Danfoss iC7 Series User Manual

The following are the selections for the parameter
Selection number
Selection name
0
Tri state
1
Open collector sink (NPN)
2
Open collector source (PNP)
3
Push pull
P 9.5.1.3 T7 Pulse Out Min. Frequency
Description: Set the frequency representing 0% of the signal.
Default Value: 0
Parameter Type: Range (0 — 100000)
Parameter Number: 4942
Unit: Hz
Data Type: REAL
Access Type: Read/Write
P 9.5.1.4 T7 Pulse Out Max. Frequency
Description: Set the frequency representing 100% of the signal.
Default Value: 100000
Parameter Type: Range (0 — 100000)
Parameter Number: 4943
Unit: Hz
Data Type: REAL
Access Type: Read/Write
7.6.3.2 Output T8 (Menu Index 9.5.2)
P 9.5.2.1 T8 Terminal Mode
Description: Select the mode for the terminal.
Default Value: 0 [Inactive]
Parameter Type: Selection
Parameter Number: 4944
Unit: -
Data Type: UINT
Access Type: Read/Write
The following are the selections for the parameter
Selection number
Selection name
0
Inactive
1
Digital Output
2
Pulse Output
P 9.5.2.2 T8 Digital Output Type
Description: Select the operating logic for the digital output.
Default Value: 0 [Tri state]
Parameter Type: Selection
Parameter Number: 4945
Unit: -
Data Type: UINT
Access Type: Read/Write
The following are the selections for the parameter
Selection number
Selection name
0
Tri state
1
Open collector sink (NPN)
2
Open collector source (PNP)
3
Push pull
P 9.5.2.3 T8 Pulse Out Min. Frequency
Description: Set the frequency representing 0% of the signal.
AQ390830267692en-000601 / 136R027358 | Danfoss A/S © 2023.06
General Purpose I/O Installation
and Configuration
Functional Extension Options
Operating Guide
