Danfoss iC7 Series User Manual

Selection number
Selection name
0
Inactive
5
Analog Output
P 9.4.3.2 T4 Terminal Type
Description: Select the type of the terminal. If voltage is selected, the unit is V. If current is selected, the unit is mA.
Default Value: 0 [Off]
Parameter Type: Selection
Parameter Number: 4936
Unit: -
Data Type: UINT
Access Type: Read/Write
The following are the selections for the parameter
Selection number
Selection name
0
Off
1
Voltage
2
Current
P 9.4.3.3 T4 Minimum Value
Description: Set the voltage or current representing 0% of the signal.
Default Value: 0
Parameter Type: Range (0 — 20)
Parameter Number: 4937
Unit: -
Data Type: REAL
Access Type: Read/Write
P 9.4.3.4 T4 Maximum Value
Description: Set the voltage or current representing 100% of the signal.
Default Value: 10
Parameter Type: Range (0 — 20)
Parameter Number: 4938
Unit: -
Data Type: REAL
Access Type: Read/Write
7.6.3 Digital Inputs/Outputs (Menu Index 9.5)
7.6.3.1 Output T7 (Menu Index 9.5.1)
P 9.5.1.1 T7 Terminal Mode
Description: Select the mode for the terminal.
Default Value: 0 [Inactive]
Parameter Type: Selection
Parameter Number: 4940
Unit: -
Data Type: UINT
Access Type: Read/Write
The following are the selections for the parameter
Selection number
Selection name
0
Inactive
1
Digital Output
2
Pulse Output
P 9.5.1.2 T7 Digital Output Type
Description: Select the operating logic for the digital output.
Default Value: 0 [Tri state]
Parameter Type: Selection
Parameter Number: 4941
Unit: -
Data Type: UINT
Access Type: Read/Write
AQ390830267692en-000601 / 136R0273 | 57Danfoss A/S © 2023.06
General Purpose I/O Installation
and Configuration
Functional Extension Options
Operating Guide
