Danfoss iC7 Series User Manual

Default Value: 0
Parameter Type: Range (0 — 100000)
Parameter Number: 4946
Unit: Hz
Data Type: REAL
Access Type: Read/Write
P 9.5.2.4 T8 Pulse Out Max. Frequency
Description: Set the frequency representing 100% of the signal.
Default Value: 100000
Parameter Type: Range (0 — 100000)
Parameter Number: 4947
Unit: Hz
Data Type: REAL
Access Type: Read/Write
7.6.3.3 Input T11 (Menu Index 9.5.3)
P 9.5.3.1 T11 Terminal Mode
Description: Select the mode for the terminal.
Default Value: 0 [Inactive]
Parameter Type: Selection
Parameter Number: 4948
Unit: -
Data Type: UINT
Access Type: Read/Write
The following are the selections for the parameter
Selection number
Selection name
0
Inactive
3
Digital input
4
Pulse input
P 9.5.3.2 T11 Signal Inversion
Description: Select whether the signal of the terminal is inverted.
Default Value: 0 [Non-Inverted]
Parameter Type: Selection
Parameter Number: 4949
Unit: -
Data Type: UINT
Access Type: Read/Write
The following are the selections for the parameter
Selection number
Selection name
0
Non-Inverted
1
Inverted
P 9.5.3.3 T11 Fast Debounce Filtering Time
Description: Set the fast debounce filtering time for the terminal.
Default Value: 0.00
Parameter Type: Range (0.00 — 63.50)
Parameter Number: 4950
Unit: μs
Data Type: REAL
Access Type: Read/Write
P 9.5.3.4 T11 Standard Debounce Filtering Time
Description: Set the standard debounce filtering time for the terminal.
Default Value: 0.00
Parameter Type: Range (0.00 — 127.00)
Parameter Number: 4951
Unit: ms
Data Type: REAL
Access Type: Read/Write
P 9.5.3.5 T11 Pulse Out Min. Frequency
Description: Set the frequency representing 0% of the signal.
Default Value: 0
Parameter Type: Range (0 — 100000)
Parameter Number: 4952
Unit: Hz
Data Type: REAL
Access Type: Read/Write
AQ390830267692en-000601 / 136R0273 | 59Danfoss A/S © 2023.06
General Purpose I/O Installation
and Configuration
Functional Extension Options
Operating Guide
