Danfoss iC7 Series

P 9.5.3.6 T11 Pulse Out Max. Frequency
Description: Set the frequency representing 100% of the signal.
Default Value: 100000
Parameter Type: Range (0 — 100000)
Parameter Number: 4953
Unit: Hz
Data Type: REAL
Access Type: Read/Write
7.6.3.4 Input T12 (Menu Index 9.5.4)
P 9.5.4.1 T12 Terminal Mode
Description: Select the mode for the terminal.
Default Value: 0 [Inactive]
Parameter Type: Selection
Parameter Number: 4053
Unit: -
Data Type: UINT
Access Type: Read/Write
The following are the selections for the parameter
Selection number
Selection name
0
Inactive
3
Digital input
4
Pulse input
P 9.5.4.2 T12 Signal Inversion
Description: Select whether the signal of the terminal is inverted.
Default Value: 0 [Non-Inverted]
Parameter Type: Selection
Parameter Number: 4955
Unit: -
Data Type: UINT
Access Type: Read/Write
The following are the selections for the parameter
Selection number
Selection name
0
Non-Inverted
1
Inverted
P 9.5.4.3 T12 Fast Debounce Filtering Time
Description: Set the fast debounce filtering time for the terminal.
Default Value: 0.00
Parameter Type: Range (0.00 — 63.50)
Parameter Number: 4956
Unit: μs
Data Type: REAL
Access Type: Read/Write
P 9.5.4.4 T12 Standard Debounce Filtering Time
Description: Set the standard debounce filtering time for the terminal.
Default Value: 0.00
Parameter Type: Range (0.00 — 127.00)
Parameter Number: 4957
Unit: ms
Data Type: REAL
Access Type: Read/Write
P 9.5.4.5 T12 Pulse Min. Frequency
Description: Set the frequency representing 0% of the signal.
Default Value: 0
Parameter Type: Range (0 — 100000)
Parameter Number: 4958
Unit: Hz
Data Type: REAL
Access Type: Read/Write
P 9.5.4.6 T12 Pulse Max. Frequency
Description: Set the frequency representing 100% of the signal.
AQ390830267692en-000601 / 136R027360 | Danfoss A/S © 2023.06
General Purpose I/O Installation
and Configuration
Functional Extension Options
Operating Guide
