Service Manual Danfoss Icon2™
© Copyright Danfoss Climate Solutions | 2023.01 | 7
AB432956914381en-010101
Re-pairing or replacing a device
When to reset a thermostat
You may reset a thermostat if you want to remove it from the system.
This can be the case because:
- The actuator outputs were paired incorrectly
OR
- The entire system requires resetting
1. Activate the thermostat by pressing on the screen.
2. Use both thumbs to press the temperature adjustment
arrow keys
until appears, as shown
in the adjacent image.
3. Press the ‘ ’ checkmark next to ‘ ’.
The thermostat has now been removed from the system.
When to reset the Master Controller
Reset the Master Controller to return to the factory settings.
This will cause all data to be deleted. Do this if you want to recommission the installation.
If you reset the Master Controller, you will also need to reset all linked thermostats and any
App or Zigbee modules.
This is necessary to be able to pair these devices again.
Hold down ‘ > ’ and then press the ‘ OK ’ button until both LEDs start ashing blue, then release the
buttons immediately.
What to do if the thermostat cannot be reset
If a wireless thermostat was reset without the regulator being
plugged into an outlet or in case of a faulty thermostat, you can use
the Icon2™ App to clear the actuator outputs.
Procedure
Once you are within Bluetooth range of the regulator, start up the
Icon2™ App.
Choose:
1. ‘Connect to existing system.’
2. Once a connection has been made,
select ‘Room Overview.’
3. Select one of the thermal
actuators that require clearing.
4. Press the three dots at the top right
on the thermostat.
5. Now select ‘Remove thermostat’.
You can now reassign the actuator
outputs.
