MAGFLO
â
Specifications
8
Type Sensor with flanges Sensor with flanges Sensor with flanges
Nominal size
1
/
2
" - 78"
1
/
2
" - 12" 1" - 48"
Temperature of medium Temperature classification
Liner: T3 + T4 T5 T6
Neoprene (standard) 30 to 160°F 30 to 160°F 30 to 160°F 30 to 160°F 30 to 160°F
EPDM
1
) -20 to 200°F -20 to 200°F -20 to 190°F -20 to 170°F -20 to 200°F
Linatex
â
rubber -40 to 160°F
2
) 0 to 160°F 0 to 160°F 0 to 160°F
Ebonite
1
) 30 to 200°F 30 to 200°F 30 to 190°F 30 to 170°F
PTFE 0 to 210°F 0 to 210°F 0 to 190°F 0 to 170°F
PTFE high temperature 0 to 350°F
Ambient temperature
Remote mount signal converter -40°F to 210°F 0°F to 105°F -40°F to 210°F
Integral mount signal converter 0°F to 120°F 0°F to 105°F 0°F to 120°F
Operating pressure
3
) [abs.psi]
Liner:
Neoprene 0.15 to 1500 psi 0.15 to 1500 psi 0.15 to 600 psi
EPDM 0.15 to 600 psi 0.15 to 600 psi 0.15 to 600 psi
Natural rubber & Linatex
â
0.15 to 600 psi 0.15 to 600 psi
Ebonite 0.15 to 1500 psi 0.15 to 1500 psi
PTFE teflon:
1
/
2
" - 24" Max. 210°F: 4.5 to 750 psi 4.5 to 600 psi
1
/
2
" - 12" Max. 350°F: 9.0 to 750 psi
Excitation frequency
1
/
2
" - 2
1
/
2
": 15 Hz
1
/
2
" - 2
1
/
2
": 7.5 Hz All sizes: 3.75 Hz
3" - 6": 7.5 Hz 3"/4": 3.75 Hz
8" - 48": 3.75 Hz 5" - 12": 1.875 Hz
54" - 78": 1.875 Hz 14" - 48": 3.75 Hz
Enclosure rating
Standard
NEMA 4X / 6 (3 ft. submersion for 30 min)
Option
NEMA 6P (30 ft. continuous submersion)
Cable entries 4 pcs. PG 13.5 - 2 others available
Mechanical load 18-1000 Hz random, 3.17 G rms in all directions, to EN 60068-2-36
Test pressure 1.5 ´ nominal pressure
Approvals FM Class 1, division 2
2. Specifications MAG 3100, MAG 3100 Ex and MAG 3100 W
2.3 Sensor MAG 3100, MAG 3100 Ex and MAG 3100 W
MAG 3100 MAG 3100 Ex MAG 3100 W
1
) With WRC and NSF (Water Research Council, UK) approval
2
) For temperature below -5°F AISI 304 or 316 flanges must be used
3
) Maximum operating pressure decreases with increasing operating temperature and with stainless steel flanges
