Danfoss Maneurop NTZ048 User Manual

98
60
156
8
Suction 179
Discharge 176
252
ø 288
413
32
Threaded oil
sight glass
Schrader
1/4"
PTC
crankcase heater
96
21
145
125
188
171
8
38
82
74
68
265
Suction rotolock
1"3/4
Discharge rotolock
1"1/4
Oil equalisation
3/8"
HM8-40
23
15
Silent block
8
OUTLINE DRAWINGS
2 cylinders
Rotolock connections size Pipe sizing Rotolock valve
Suction Discharge Suction Discharge Suction Discharge
NTZ096
NTZ108
1”3/4 1”1/4 7/8” 3/4” V07 V04
NTZ136 1”3/4 1”1/4 1"1/8” 3/4” V02 V04

Danfoss Maneurop NTZ048 Specifications

General

Brand	Danfoss
Model	Maneurop NTZ048
Category	Air Compressor
Language	English
