Danfoss OSQA - PP-Connection End Cover Removal

4.
Screw out the seat (21) using a 6 mm socket spanner.
Removing end cover at PP-connection
1.
Unscrew screws (8x81) with spring washer (8x80) using a 13 mm
socket spanner and screw (83)
with spring washer (82) using a 10 mm Hex key.
2. Remove end cover (66).
Spring stop (30) and springs (28, 29 and 13) will follow the end cover.
Service Manual
OSQA/OSQB
Disassembly
12 |
©
Danfoss | July 2016 HN25D293 | AX00000127en-US0101
