Balancing
calculation
of a project
with central
pressure
input –
procedure
(continued)
5. PFM 5001 will balance the
two projects separately.
Next, it will rebalance the
side of the project that
requires higher pressure
after the common valve.
Finally, will be corrected the
preseting of the common
valve.
Measuring
actual flow
1. Click on Branch tab and
select branch to measure.
Click on Measure icon at Real
flow line.
2. The flow value measured
will be entered under the
“Real flow” parameter of the
selected branch.
