Specifications (continued)
Description Units Minimum Typical Maximum Comment
Input impedance
(5 V/GND)
kΩ 12 — 13.1 Pull up to +5 V or pull down
to ground.
Input impedance
(2.5 V)
kΩ 6.64 — 7.02 Pull to +2.5 V.
Middle and low range DAFR
Input impedance kΩ 91 — 175 No pull up or pull down.
Input impedance
(5 V/GND)
kΩ 12.7 — 14.0 Pull up to +5 V or pull down
to ground.
Input impedance
(2.5 V)
kΩ 6.86 — 7.26 Pull to +2.5 V.
If the frequency goes to zero, the data will not decay over time, it will be updated once a new pulse is
seen, or times out. It is possible to monitor the count of pulses to know when the frequency reading is
updated.
Output types
•
Digital (DOUT)
•
Digital/PVG valve reference power (DOUT/PVGpwr)
•
Pulse width modulated (PWM/DOUT/PVGOUT)
Output pins available on MC0XX-1XX Controller Family
PLUS+1
®
module
DOUT
(3 A)
DOUT/PVGpwr
(3 A)
PWMOUT/DOUT/PVGOUT
(3 A)
MC012-110/112 2
MC024-110/112 4
MC024-120/122 8
MC050-110/112 3 3 10
MC050-120/122 6 2 6
MC050-155/15B 1 2
IOX012-110 2
IOX024-120 8
OX012-110 6
OX024-110 4 2 10
PLUS+1
®
modules feature user-configurable output pin parameters. Output pin parameters are
configured using PLUS+1
®
GUIDE templates.
W
Warning
Unintended movement of the machine or mechanism may cause injury to the technician or bystanders.
The module will be powered up if battery voltage is applied to the module's output pin. To protect
against unintended movement, secure the machine.
C
Caution
Warranty will be voided if module is damaged.
Avoid significant current driven back through an output pin.
Technical Information
PLUS+1® MC0XX-1XX Controller Family
Inputs/outputs types and specifications
©
Danfoss | April 2018 L1321895 | BC00000227en-US0401 | 13
