MC controllers general ratings (continued)
Description Units Minimum Maximum
Comment
Allowable module supply
voltage
Vdc 9 36
*
Minimum allowable supply voltage
for the MC038-010 module CPU
power pin is 6 Vdc.
Module sensor supply
voltage
Vdc 4.8 5.2 Sensor voltage drops below the
minimum value if module supply
voltage < 9 Vdc. Exception for
MC050-055/05B and MC024-01A, see
Sensor power supply ratings on page
20.
Analog input voltage levels Vdc 36
*
Allowable output load
current (per pin)
A See individual module date sheets.
Module allowable total
output current
A See individual module data sheets.
All modules Ingress
Protection (IP) rating
**
IP 67
All modules CE rating CE compliant.
*
MC050-055/05B input voltage maximum is limited to 16 Vdc.
**
The PLUS+1® modules IP 67 rating is only valid when the module mating connector is in place and unused
connector pin positions have sealing plugs installed.
Environmental testing criteria
Climate environment
Description Applicable standard Comment
Storage temperature IEC 60068-2-1, test Ab, IEC
60068-2-2 test Bb
Operating temperature IEC 60068-2-1, test Ab, IEC
60068-2-2 test Bd
Thermal cycle IEC 60068-2-2, test Na, IEC
60068-2-38 (partial)
Humidity IEC 60068-2-78, IEC
60068-2-30 test Db
Damp heat steady state and cyclic.
Degree of protection IEC 60529
Chemical environment
Description Applicable standard Comment
Salt mist IEC 60068-2-58 test Kb
Chemical resistance ISO 16750-5
Mechanical environment
Description Applicable standard Comment
Vibration IEC 60068-2-6 test Fc, IEC
6008-2-64 test Fh
Bump IEC 60068-2-29 test Eb
Technical Information
PLUS+1® MC0XX-1XX Controller Family
Product ratings
