Table 142: Power Losses for Non-fusible Disconnect Option, 525–690 V
Model
525–550 V [W]
551–690 V [W]
–
NO
HO
NO
HO
N110
4
2
3
2
N132
5
4
5
3
N160
8
5
7
5
N200
12
8
11
7
N250
17
12
16
11
N315
24
17
22
16
N355
33
24
30
22
N400
42
29
38
27
N500
52
35
47
32
N560
20
16
19
14
N630
23
20
23
19
N710
32
24
30
22
N800
44
32
40
30
11.6.4 Molded-case Circuit Breaker (MCCB) Losses
Table 143: Power Losses for MCCB Option, 380–480 V
Model
380–440 V [W]
441–480 V [W]
–
NO
HO
NO
HO
N110
25
18
20
14
N132
38
25
32
20
N160
56
38
51
32
N200
54
35
45
32
N250
80
54
68
45
N315
120
80
100
68
N355
62
52
50
42
N400
80
62
66
50
N450
92
70
77
66
N500
112
92
88
77
N560
92
73
74
57
