Danfoss PTU 025 User Manual

Model
Enclosure size (380–480 V)
Enclosure size (525–690 V)
N630
–
E5h
N710
–
E6h
N800
–
E6h
3.4.3 Type Code Identification
Table 4: Product Group Code
Character position
Code
Description
1–3
PLV
VLT
®
Enclosed Drives
Table 5: Drive Series Codes
Character position
Code
Description
4–6
102
VLT
®
HVAC Drive FC 102
103
VLT
®
Refrigeration Drive FC 103
202
VLT
®
AQUA Drive FC 202
302
VLT
®
AutomationDrive FC 302
Table 6: Low-harmonic Filter Codes
Character position
Code
Description
7
T
None
P
Passive filter, THDi=5%, 50 Hz
H
Passive filter, THDi=8%, 50 Hz
L
Passive filter, THDi=5%, 60 Hz
U
Passive filter, THDi=8%, 60 Hz
Table 7: Mains Voltage Codes
Character position
Code
Description
8
4
380–480 V
5
380–500 V
7
525–690 V (525–600 V for UL)
Table 8: Norms and Standards Codes
Character position
Code
Description
9
I
IEC
U
UL
AQ262141314214en-000301 / 130R088024 | Danfoss A/S © 2021.11
Product Overview
VLT® HVAC Drive FC 102
Operating Guide

Danfoss PTU 025 Specifications

General

Brand	Danfoss
Model	PTU 025
Category	DC Drives
Language	English
