5.7.6.9 Signal Lights and Reset Buttons
Table 62: Door-mounted Option Type Codes
Character posi-
tion
Code
Description
28–29
D1
Signal lights and reset button
DA
Signal lights and reset button + emergency switch off and emergency push-button
DB
Signal lights and reset button + STO with emergency push-button (no functional safety)
DC
Signal lights and reset button + STO/SS1 with emergency push-button + safely limited speed (TTL
encoder)
DE
Signal lights and reset button + STO/SS1 with emergency push-button + safely limited speed (HTL
encoder)
The signal light and reset button option includes signal lights on the control compartment door for run and fault states of the AC
drive. The door also has a button for the reset function of the drive.
5.7.6.10 Emergency Switch Off
Table 63: Door-mounted Option Type Codes
Character position
Code
Description
28–29
D2
Emergency switch off + emergency push-button
DA
Signal lights and reset button + emergency switch off and emergency push-button
The emergency switch off option uses an input contactor to disconnect the drive from mains. Pushing the emergency stop push-
button on the control compartment door opens the control circuit of the input contactor.
5.7.6.11 STO with Emergency Push-button on Door
Table 64: Door-mounted Option Type Codes
Character position
Code
Description
28–29
D3
STO with emergency push-button (no functional safety)
DB
Signal lights and reset button + STO with emergency push-button (no functional safety)
This option provides the STO (Safe Torque Off) function via an emergency push-button mounted on the door of the control com-
partment. The control terminals of the control card are extended from inside the drive module and routed out to the terminal block
set -XD2 in the control compartment. The emergency push-button is wired between terminals -XD2.10 and -XD2.19.
Activating the emergency push-button prevents the unit from generating the voltage required to rotate the motor. The option pro-
vides:
Safe Torque Off (STO), as defined by EN IEC 61800-5-2.
Stop Category 0, as defined in EN 60204-1.
5.7.6.12 STO/SS1 with Emergency Push-button + Safely Limited Speed (TTL Encoder) on Door
Table 65: Door-mounted Option Type Codes
Character position
Code
Description
28–29
D4
STO/SS1 with emergency push-button+safely limited speed (TTL encoder)
DC
Indicator lights and reset button + STO/SS1 with emergency push-button+safely limited speed
(TTL encoder)
