Proportional Valve Group PVG 32
PVEM Control Specification
Supply Voltage (U
DC
)
Rated/Range 11 → 32 V
DC
Max. ripple 5%
Signal Voltage (U
S
)
Neutral U
S
= 0.5 • U
DC
Q: P → A U
S
= (0.5 → 0.25) • U
DC
Q: P → B U
S
= (0.5 → 0.75) • U
DC
Signal Voltage PWM (U
S
)
neutral U
S
= 50% DUT
Q: P → A U
S
= 50% → 25% DUT
Q: P → B U
S
= 50% → 75% DUT
PWM Frequency (U
S
) Recommended > 200 Hz
Input Impedance Rated 12 kΩ
Input Capacitance Rated 100 nF
PVEA/PVEH/PVES Control Specification
Supply Voltage (U
DC
)
Rated/Range 11 → 32 V
DC
Max. ripple 5%
Signal Voltage (U
S
)
Neutral U
S
= 0.5 • U
DC
Q: P → A U
S
= (0.5 → 0.25) • U
DC
Q: P → B U
S
= (0.5 → 0.75) • U
DC
Signal Voltage PWM (U
S
)
neutral U
S
= 50% DUT
Q: P → A U
S
= 50% → 25% DUT
Q: P → B U
S
= 50% → 75% DUT
PWM Frequency (U
S
) Recommended > 1000 Hz
Input Impedance Rated 12 kΩ
Input Capacitance Rated 100 nF
PVE kontrol specifikationer
PVE control specifications
PVE Steuerungsspezifikationen
PVE spécifications de contrôle
PVEO Control Specification
Supply Voltage (U
DC
)
Rated 12 V
DC
24 V
DC
Range 11 → 15 V
DC
22 → 30 V
DC
Max. ripple 5 %
PVE driftsbetingelser
PVE operating conditions
PVE Betriebsbedingungen
PVE conditions de
fonctionnement
PVEO/PVEH/PVES Operating Conditions
Pilot Pressure
Nominal 13.5 bar [196 psi]
Minimum 10.0 bar [145 psi]
Maximum 15.0 bar [220 psi]
Storage Temp. Ambient -50°C → 90°C [-58°F → 194°F]
Operating Temp. Ambient -40°C → 90°C [-40°F → 194°F]
Oil Viscosity
Operating range 12 → 75 cSt [65 → 347 SUS]
Minimum 4 cSt [39 SUS]
Maximum 460 cSt [2128 SUS]
Oil Cleanliness Maximum 18/16/13 (acc. to ISO 4406)

Danfoss PVG 32 Specifications

General

Category	Control Unit
Maximum working pressure	350 bar
Size	32
Type	Proportional Valve
Maximum operating pressure	420 bar
Porting pattern	ISO 4401
Electrical connection	AMP
