SET1E
12
GB
DANFOSS RANDALL
SET1E
MAINS
SPARE TERMINAL
Where disconnected
leads should be
terminated
LOAD
Additional terminal block
is required where these
disconnected leads (or
pairs) should be terminated
N L ON COM OFF
NL 2 4 5 6ABCD
ACL LS111 N L 4 3 1 2
DANFOSS RANDALL SET 1 N L 2 4 5 6
DANFOSS RANDALL 911 N L 2 6 5 4
DANFOSS RANDALL 103/103E 5 6 2 1 3 -
DANFOSS RANDALL 3020 1,7 6 2 4 - - 3 5
DANFOSS RANDALL TSR2 3 2 4 5 1 - 6 7
GRASSLIN 45, 45A, 45E 2 1 4 3 -
HORSTMANN 424 EMERALD & PEARL
AUTO RANGE
NL1 2 4 3 - 5
HORSTMANN 423 PEARL
EMERALD & TOPAZ
NL 1 4 3 -256
HORSTMANN KMK2A YMK2 3 4 2 1 -
HONEYWELL ST6100A N L 3 4 1 2
HONEYWELL ST6100C N L 3 4 1 2
HORSTMANN 425 CORONET N L 1 4 5 6 2 3
LANDIS & GYR RWB3 N L 1 4 - 3 2
