SET1E
8
GB
N L 1 2 3 4 5 6
3 amp
fuse max.
SPARE LOAD
ON OFF
Mains
Supply
N
L
Timeswitch
Terminals
Pump
N
N
L
CALL
COM
Room
Stat
3.3 Typical Control of Pump For Central Heating
on a Solid Fuel System
