VLT® 5000 Crane
Initialisation [3] is selected if the factory setting of
the unit is desired without resetting parameters
500, 501 + 600 - 605 + 615 - 617.
NB!:
The motor must be stopped before initialisation
can be carried out.
Procedure for initializing:
1. Select Initialisation.
2. Press the [OK] key.
3. Cut off the mains supply and wait for the
light in the display to go out.
4. Connect to mains.
Manual initialisation can be carried out by holding down
three keys at the same time as the mains voltage is
connected. Manual initialisation sets all parameters to
the factory setting, except 600-605. The procedure
for manual initialisation is as follows:
1. Disconnect the mains voltage and wait for the
light in the display to disappear.
2. Hold down [DISPLAY/STATUS]+[MENU]+[OK] while
at the same time connecting the mains supply. The
display will now read MANUAL INITIALIZE.
3. When the display reads UNIT READY, the frequency
converter has been initialized.
621-631 Type plate
Value:
Par.
no
Description
Nameplate
Display text
621 Unit type (DRIVE TYPE)
622 Power section (POWER SECTION)
623 V LT ordering number (VLT OR DERING NO)
624 Software version (SOFTWARE VERSION)
625 LCP identification no. (LCP VERSION)
626 Database identification no. (DATABASE VER.)
627 Power parts version (POWER UNIT DB ID)
628 Application option type (APP. OPTION)
629 Application ordering (APP. ORDERING)
630 Communication option type (COM. OPTION)
631 Communication ordering (COM: ORDERING)
Function:
The unit’s main data can be read out from parameters
621 to 635 Type plate using the LCP control unit or
serial communication. Parameters 640 - 642 can
also be seen on the unit’s integral display.
Description of choice:
Parameter 621 Type plate: Unit type:
Givesunitsizeandmainsvoltage.
Example: VLT 5250 400-500V.
Parameter 622 Type plate: Power section:
The power section states the given powe
r
section being used.
Parameter 623 Type plate: VLT ordering number:
Ordering number states the ordering number of the
VLT type in question. For example: 175Z3120.
Parameter 624 Type plate: Software v
ersion no.
The unit’s present software version number
appears here.
Example: V 20.00
Parameter 625 Type plate: LCP ID number:
The ID number of the unit’s LCP appears here.
Example: ID 1.42 2 kB
Parameter 626 Type plate: Database ID number:
The ID number of the software’s database appears here.
Example: ID 1.14.
Parameter 627 Type plate: Power section version:
The ID number of the unit’s power section appears here.
Example: ID 1.15.
Parameter 628 Type plate: Application option type:
Here you can see which types of application options
are installed in the frequency converter.
Parameter 630 Type plate: Communication option type:
Here you can see which types of communication
options are installed in the frequency converter.
✭ = factory setting. () = display text [] = value for use in communication via serial communication port
MG.50.N4.02 - VLT is a registered Danfoss trademark
72
